Daiwa Tanacom 800 Electric Reels
The Tanacom 800 is the mid-size of the modern Tanacom family — the 1200's little brother, built on the same redesign. It holds 660 yards of 80 lb J-Braid (220 yards more than the Tanacom 750 it replaced), retrieves about 30% faster, and the whole package is saltwater-sealed for an end-of-day hose-down.
The motor moved inside the spool
Earlier Tanacoms carried their motor out front. Like the 1200, the 800 tucks the motor and gearing inside the spool: the same dependable motor delivers more power, speed, and efficiency, the frame and side plates stay rigid, and the repositioned bearings see less water. No-load retrieve runs 140 m/min (about 460 ft/min), with 70 lb (35.1 kgf) of momentary winding power for heavy lifts.
Drag and control
Max drag is 55 lb (25 kg), sealed against saltwater. The Power Lever gives variable-speed control under your thumb, or crank by hand through the 2.1:1 gears and aluminum round knob at 23.1" per turn. The oversized line-guide aperture passes swivels and bulky knots straight through the levelwind — wind a kite rig right to the rod tip.
Electronics that earn their keep
The LED dot-matrix counter reads depth in feet or meters with selectable display languages and a built-in counter lamp. An adjustable auto-stop halts the retrieve short of the surface, the inverse counter and line-feeding function manage the drop, and a chumming timer re-feeds line on a schedule. Fully sealed electronics, an overload circuit breaker, and a rod clamp for kite duty complete it.
Like every electric reel it wants a dedicated battery: it runs on 12 V DC (16.8 V max) — a Daiwa electric-reel battery is the recommended source, and it will not run on household AC or 24 V boat power. Daiwa backs US Tanacoms with a one-year warranty.
Key features
- Motor-in-spool design — more power and speed from a rigid, compact frame
- 660 yd of 80 lb J-Braid — deep-drop and kite capacity
- 55 lb (25 kg) sealed max drag
- 140 m/min (~460 ft/min) no-load retrieve
- Oversized line-guide aperture — swivels and knots pass through
- Auto-stop, chumming timer, line feeding, alarms — dot-LED counter in feet or meters
- Rod clamp included — 1-year US warranty
Specifications
| Specification | TANACOM 800 |
|---|---|
| Gear Ratio | 2.1:1 |
| Weight | 1,910 g (67.4 oz) |
| Max Drag | 55 lb (25 kg) |
| Line Per Crank | 23.1" |
| Ball Bearings | 4 |
| Braid Capacity (J-Braid) | 65 lb / 880 yd · 80 lb / 660 yd · 100 lb / 550 yd |
| Mono Capacity | 30 lb / 550 yd · 40 lb / 380 yd |
| No-Load Winding Speed | 140 m/min (459 ft/min) |
| Momentary Winding Power | 70 lb (35.1 kgf) |
| Handle | Power Lever + aluminum round knob |
| Power Supply | 12 V DC (16.8 V max) |
| Depth Display | 0–9,842 ft (3,000 m), feet or meters |
Electric reel power & care basics
Electric reel power & care basics
Power. Electric reels run on DC battery power only — never household AC, and never a 24V boat system unless the reel is rated for it (this reel's rating is in the spec table). A dedicated, waterproof reel battery — Daiwa's Super Lithium or Tough Battery series, or a marine deep-cycle — beats running off the boat, whose voltage swings can trip the reel's protection circuit mid-fight. Use only a lithium pack the maker specifies for your model.
If it slows down or stops: it's usually the battery, not the reel. Below about 10V the reel restricts its winding power, and an overload breaker pauses winding for a few seconds under an excessive load or heat spike, then resumes. A cord connected with reversed +/- polarity won't conduct at all.
Care. Rinse gently in cool fresh water (under 30°C/86°F) — mild dish soap and a soft sponge for grime, no solvents or stiff brushes — then dry completely, loosen the drag, and drain the handle knob before storage. Store the power cord disconnected and treat it as a consumable: Daiwa recommends a new cord every two years or roughly 60 outings. And don't open the reel up yourself — the electronics aren't user-serviceable.
